529-03
DCI pipe gasket for gas

To be used for gas applications when connecting BAIO® spigot ends, PE fusion ends, steel welding ends, and DCI pipes in BAIO® sockets.

Material: NBR
Max. operating Pressure: Gas: 16 bar
Medium Gas
Order Nr.

DN

Operating pressure max.

Description
Medium Weight Specification Basket
5290801000
80 16 bar sealing for DCI pipes 0,12 kg
5291001000
100 16 bar sealing for DCI pipes 0,18 kg
5291251000
125 16 bar sealing for DCI pipes 0,15 kg
5291501000
150 16 bar sealing for DCI pipes 0,24 kg
5292001000
200 16 bar sealing for DCI pipes 0,35 kg
5292501000
250 16 bar sealing for DCI pipes 0,45 kg
5293001000
300 16 bar sealing for DCI pipes 0,60 kg
5295080000
80   surcharge 0,00 kg
5295100000
100   surcharge 0,00 kg
5295125000
125   surcharge 0,00 kg
5295150000
150   surcharge 0,00 kg
5295200000
200   surcharge 0,00 kg
5295250000
250   surcharge 0,00 kg
5295300000
300   surcharge 0,00 kg
Wish List

All BAIO® sockets are equipped with BAIO® lip gasket (BLD®) for water. The surcharges quoted in the table include factory preinstalled gas-resistant DCI pipe gaskets, on the one hand, and the surcharge for the DCI pipe gasket for water, on the other hand.
